Relé de Monitoreo de Voltaje Mini TG30S Trifásico Protección contra Rayos Protector de Secuencia de Fase Proyectos de Electrónica de Construcción para Aplicaciones Industriales

- Dynamic phase loss, static phase loss protection: refers to the phase failure of any phase when the protected device is in the running state or non operating state. The indicator light is in the form of red light and priority
- Wrong phase protection: A protection measure to prevent the phase sequence of L1, L2, L3 three phase AC power supply from being connected incorrectly. Instant action. The indicator light is in the form of yellow light.
- Voltage Unbalance Protection: Refers to a voltage imbalance that will affect the safe of the device. When the voltage imbalance rate is higher than 8%. The form of the indicator light is: the lack of phase red light is on, and priority.
- Delay protection: When there is a fault, the monitor will delay after 1~2 seconds, and the relay will release.
- The protection function of the monitor is not affected by the current of the line or load, the inrush current, the unbalanced current and the nature of the load. Long term work with full performance and full climate. Power consumption is no more than 2W.
